Understanding Surge Analysis for Pumping Station Rising Mains

Updated: Sep 20

In the realm of water and wastewater engineering, the integrity and reliability of pumping stations are crucial. One critical aspect of ensuring their effective operation is conducting a surge analysis on the rising main. But what exactly is a surge analysis, and why is it so important? Let’s delve into the reasons behind this analysis and its significance in maintaining a robust and efficient pumping system.



What is surge analysis?


Surge analysis is a method used to evaluate the impact of sudden changes in flow conditions within a pipeline system, such as a rising main. It is required for rising main lengths that exceed 500 meters and can alter the design of the pumping station or key protective measures (see more information below on this). A rising main is a type of pipeline used to transport water or wastewater vertically from a lower elevation to a higher one, often encountered in pumping stations. Surge analysis specifically examines how pressure fluctuations, or "surges," occur within the pipeline when there are rapid changes in flow rates, such as pump start-ups, shutdowns, or valve operations.


When do I need a surge analysis?


When specifically applied to sewage or surface water pumping stations, we suggest that a details surge analysis should be completed if the rising main is greater than 500 metres or other specific conditions exist like connecting into an existing rising main for example. With the Design and Construction Guidance for when designing and building pumping station for adoption, clause D6.3.3 states the following:


"3.      A rising main should be laid to a minimum gradient of 1:500 rising and 1:300 falling, with sewage-type air release valves provided at high points to facilitate air removal. However, a continuously-rising pipeline without air valves is preferred. For rising mains longer than approximately 500 m, the following factors should be considered:


a.)   retention time and septicity (it may be necessary to use chemical dosing or to reduce retention times by using a smaller main or a smaller sump);

b.)   effect of hydraulic surge and cyclic loading on fatigue life of the material (copies of calculations/reports on surge analysis should be sent to the sewerage company);

c.)   the effect of air accumulating at high points in the system (it may be necessary to include a special air release valve);

d.)   the drawing in of air after running pump units "on snore" (it may be necessary to include a special air release valve);

e.)   provision should be made for access for cleansing; and

f.)     washout facilities at any low points."


The whole document can be downloaded here https://bit.ly/46lgTff


Our design teams will advise you early if a surge analysis will be required and will guide you through the process.


Why is surge analysis important?



Preventing pipeline damage



Pressure Surges: When pumps start or stop abruptly, or when valves are opened or closed quickly, pressure changes can create significant hydraulic surges in the pipeline. These surges can lead to extremely high or low pressure conditions, which might exceed the design limits of the pipeline and cause physical damage. Surge analysis helps predict these pressure fluctuations and design the system to withstand them, preventing potential bursts or leaks.



Ensuring system reliability



Operational Stability: By understanding how surges affect the pipeline, engineers can design measures to mitigate their impacts. This includes selecting appropriate pump control strategies, integrating surge protection devices (like surge tanks or air chambers), and optimizing valve operations. Such precautions enhance the reliability and stability of the entire pumping system, ensuring consistent operation and reducing downtime.



Extending asset lifespan



Wear and Tear: Repeated exposure to surge conditions can accelerate wear and tear on the pipeline, joints, and associated components. By addressing surge issues proactively through design adjustments and protective measures, the lifespan of the infrastructure can be extended, leading to cost savings on repairs and replacements.



Reducing operational costs



Efficiency: Surges can cause inefficiencies in the system, such as increased energy consumption and potential damage to pumps and other equipment. Surge analysis helps in designing systems that operate more smoothly and efficiently, reducing unnecessary energy costs and operational expenses.



Compliance with standards



Regulatory Requirements: Many regions have strict regulations and standards regarding the design and operation of water and wastewater systems. Surge analysis ensures that the pipeline system complies with these regulations, helping to avoid legal and financial penalties.



Key Components of Surge Analysis



Modeling Flow Dynamics: Surge analysis involves creating detailed hydraulic models of the pipeline system. These models simulate various operating conditions and predict how pressure surges will behave under different scenarios.



Designing Mitigation Measures: Based on the analysis, engineers can design surge control measures, such as:



·         Surge Tanks: To absorb pressure spikes.

·         Air Chambers: To allow air to enter and cushion pressure changes.

·         Pressure Relief Valves: To release excess pressure safely.



Testing and Validation: After implementing surge protection measures, it’s crucial to validate the system through testing and simulations to ensure that it effectively mitigates surge impacts.



Surge analysis is a fundamental aspect of designing and maintaining a reliable and efficient pumping station rising main. By understanding and addressing the impact of pressure surges, engineers can prevent pipeline damage, enhance system reliability, extend the lifespan of infrastructure, and reduce operational costs. This proactive approach ensures that water and wastewater systems operate smoothly, efficiently, and in compliance with regulatory standards, ultimately contributing to the overall sustainability and resilience of water management infrastructure. Surge analysis is a requirement under both Sewers for Adoption and DCG for rising main lengths that exceed 500 metres. The results of this can alter the design of the pumping station, or key protective measures within the design as a direct result of surge, so it is vital that early analysis takes place. To be sure that your pumping station will perform efficiently and the rising main is protected, contact us to undertake the necessary surge analysis on your pumping station rising main.



In summary, surge analysis isn’t just a technical exercise; it’s a crucial step in safeguarding the integrity and functionality of critical infrastructure.
